Transport Systems

Safe transport of blood products

Facts & Figures

Cat.No.: MT

5 sizes

Model

2.2 - 44 l

Volume

1 - 25

Plasma bags (450 ml)

TRANSPORT SYSTEMS for the safe transport of blood products

The model range MT consists of five passive transport systems and one active transport box, working with a compressor. B Medical Systems transport systems are ideal for intensive use with many transport applications, even under difficult climatic conditions. Passive MT models are conform with the European agreement on the international transport of hazardous goods by Road (ADR), by Rail (RID), by Sea (IMDG) and with the international agreement for air transport (ICAO-TI / IATA-DGR). For all passive transport boxes eutectic cooling systems are available as an option (-32 °C, +4 °C, +22 °C and +37 °C).

Compliant to ADR I RID I IMDG I ICAO-TI I IATA-DGR I Medical Device Class IIa according to MDR (EU) 2017/745



Model sizes
ModelGross volumeStorage capacity (bags gross volume)Cooling system
MT22.2 l1 (450 ml) / 2 (270 ml)Passive
MT48 l4 (450 ml) / 6 (270 ml)Passive
MT820 l8 (450 ml) / 14 (270 ml)Passive
MT1224 l15 (450 ml) / 25 (270 ml)Passive
MT2544 l25 (450 ml) / 40 (270 ml)Passive

Areas of applications

  • The polyurethane foam injected into the double walls of these transport systems is free of CFC and HCFC and ensures optimum insulation and protection of quality of the transported goods, especially with longer transport times.
  • Due to the outer casing's self-insulation against the environment, the B Medical Systems transport systems maintain a stable temperature even at higher ambient temperatures.
  • The special transport boxes, made from rotationally moulded polyethylene (a literally indestructible synthetic), feature an extraordinarily sturdy casing that is almost impervious to external forces, e.g; caused by bumps and falls, whose sturdiness have been proven in drop tests.
  • The corrosion free material offers easier and safer handling and is light weight. All transport systems can easily and thoroughly be cleaned and disinfected with conventional disinfectants. There are no inaccessible corners or areas inside the transport systems.
  • The clasps can be sealed or equipped with locks and are therefore protected against unauthorised access during transport
