Automatic Aspiration System
Efficient liquid collection solutions
Facts & Figures
Cat.No.: AA02+AA04+AA24
170x220x160 mm
Dimensions (WxDxH)
12 l/min. air
Max. capacity
5.2 kg
Weight
100 Watt
Power
Extraction systems are used in laboratories to extract and collect liquids and then remove them from cuvettes, microtitre plates, culture flasks, tubes and petri dishes. This is a routine task that requires equipment that is compact but also easy to operate and install.
Hettich has three models of extraction systems, ranging from a simple to an automatic system. Various accessories are available for the systems and, if necessary, an expansion kit. The bottle quick-release couplings are easy to remove and empty.
The advantage of the automatic system (AA 02/04/24) is that it can be connected to multiple (up to 4) bottles and extraction points and that this system automatically switches off when the vacuum is reached. Standard equipped with
- Membrane vacuum pump of 100 mBar (AP30)
- 1 bottle of 2 or 4 litres (with quick-connector)
- 1x hose set incl. membrane filter 0.2 μm, 2x AW 01 hose clip Ø 6 mm, 1x ventilation insert for autoclaving Ø 6 mm and 1x silicone hose 3m (6 x 2 mm)
- Handle with flow control AH01 (see accessories for details)
- User manual English/German
The suction speed of this AA model is approx. 12 litres of air per minute. For proper operation, we recommend using the handle and the stainless steel bottle holder (if you do not place the bottle on the unit) to prevent the bottle from tipping over and clogging the filter and stopping the system. The AA24 is our automatic system with 2 handles.
Aspiratin System AA02: Cat. no. 981323101
Aspiration System AA04: Cat. no. 981323001
Aspiration System AA24: Cat. no. 981323201
Advantages
User friendly
- The Aspiration systems are easy to install and can optionally be fitted with a nozzle using Luer-Lock adapter which allows the attachment of a Pasteur pipette. Attachments are also available with 1, 4 or 8 channels. A foot switch is also an option. For more information see the models 'standard (AC)' or 'automatic (AA)'.
The right accessories and options for this product
Handle with flow control AH01 consisting of:
- 1x Handle AH01-AH01
- 1x 90 ° Adapter (100210057)
- 1x Plastic adapter Ø 6,6 mm (100210058)
- 1x Plastic adapter Ø 6 mm (100210064)
- 1x Silicone tube 50 mm (Ø6 x 2 mm)
Cat.No.: 800013200
Spare 4-litre bottle with fast lock in screw cap
Cat.No.: 800014700
Spare 2-litre bottle with fast lock in screw cap
Cat.No.: 800014600
Spare set of tubes consisting of:
- 1x Membrane filter 0,2 μm (100210019)
- 2x AW 01 Hose clip Ø 6 mm (100210028)
- 1x Ventilation insert for autoclaving Ø 6 mm (100210002)
- 1x Silicone tube 3m (6 x 2 mm) (100210014)
Cat.No.: 800015700
Spare vacuum pump AP30 (12 l/min air, 100 mBar abs).
Cat.No.: 800015100
Stainless steel bottle holder for 4 bottle to prevent the bottle from tipping over and causing the filter to plug and the system to stop working.
For the 2 litres bottle it is art. no. 800014950
Cat.No.: 800014960
Spare set of 3 membrane filters 0,2 μm
Cat.No.: 800015800
Expansion set AK02 , consisting of:
- 1x bottle holder for 2 litres bottle on stainless steel table
- 1x 2 litres bottle with fast lock in screw cap
- 1x set of tubes (see item 800015700)
- 1x handle with flow control (see item 800013200)
Cat.No.: 800014800-01
Adapter with suction rake and Luer-Lock connection (AR50) : cat. no. 800013720 (picture)
Other options:
- Stainless steel adapter with Luer-Lock
(AR5, 4 channel) : cat. no. 800013740 - Stainless steel adapter without Luer-Lock
(4 channel) : cat.no. 100210060 - Stainless steel adapter, without Luer-Lock
(8 channel) : cat. no. 100210059 - Aspiration rake with Luer-Lock
(8 channel) : cat. no. 800013700 - Aspiration rake withour Luer-Lock
(8-channel) : cat. no. 800015600
Spare screw cap for the 2 litres bottle
For the 4 litres bottle, Cat. no. 800014500
Cat.No.: 800014400
- Stainless steel suction adapter, length 150 mm: Cat. no. 800013400
- Stainless steel suction adapter, length 200 mm: Cat. no. 800013500
- Stainless steel suction adapter, length 60 mm: Cat. no. 800013300
All are with Luer-Lock
Cat.No.: 800013500
Spare power cord, cat. no. 980000101
Spare power cord U.K.. cat. no. 980000301
Spare power cord Swiss, cat. no. 980000201
Cat.No.: 980000101
Other accessoires are i.e.:
- Connector for tubes (angled), Cat. no. 100210028
- Connector to ventilate during autoclaving, Cat. no. 100210002
- 90° adapter Lw/M, Cat. no. 100210057
- Stainless steel holder for handle, Cat. no. 800050700
